Inground Scissor Lift TVL635

9 / 9

features

·Underground installation, saving work space
·Equipped with a full set of imported oil cylinders and ball valve components,with reliable quality.
·The platform length is adjustable and suitable for different models.
·Hydraulic volume synchronized cylinder, platform operation is synchronous and stable.
·24V limit control box, safe, simple and convenient.
·Hydraulic lock and mechanical double-tooth safety claw, double insurance, safe and reliable.
·Overload redundancy design, passed 120% dynamic loading and 150% express loading tests.

Specifications

Rated load

3500kg

Lifting height

2130mm

Initial height

330mm

Lifting time

≤55s

Lowering time

≥20s

Platform length

Standard 1550-1740mm,double pull 1650-2040mm

Platform width

550mm

Power

2.2kw

Voltage

AC 400V or 230V±5% 50Hz

Hydraulic Oil

12L( Winter: N32# Summer: N46# )

Net weight

Standard 696kg, double pull-out 722kg

Working Temperature

5-40℃

Air Pressure

0.6-0.8Mpa
